7KG Dragonfish Standard with L20T

De Dragonfish-serie is een eVTOL-toestel (vertical takeoff and landing) met kantelrotoren, ontworpen voor het leveren van intelligentie-, bewakings- en verkenningsdiensten (ISR) met behulp van meerdere sensoren. De Dragonfish is ultra-draagbaar, heeft geen startbaan nodig en is binnen 5 minuten klaar voor vertrek vanuit de koffer. Het toestel vereist geen extra lanceer- of vangapparatuur en kan zowel automatisch als handmatig opstijgen en landen.

Met een vliegtijd tot wel 179 minuten en een bereik tot 45 km* (dat onbeperkt kan worden uitgebreid met repeaters), biedt dit systeem toonaangevende prestaties op het gebied van uithoudingsvermogen en inzetbaarheid. De Dragonfish beschikt over een quick-release systeem voor het snel wisselen van payloads, met diverse toonaangevende EO/MWIR-sensoropties. Dankzij geavanceerde vluchtcontrole- en tracking-algoritmen kan de Dragonfish door één enkele operator worden bediend met minimale training.

Type
- Drone bundle
Merk
- Autel

Vraag offerte aan

The Dragonfish Series UAV is a vertical takeoff and landing (eVTOL), tiltrotor aircraft used to provide multi-sensor intelligence, surveillance, and reconnaissance (ISR) Services. The Dragonfish is ultraportable, runway independent, and assembles within 5 minutes from case to takeoff. The Dragonfish does not require any additional launch equipment or recovery equipment and can take off and land automatically or manually. Delivering up to 179 minutes of flight time, and a range of up to 45km*, or extended indefinitely with repeaters the system offers class leading performace in endurance and capability. The Dragonfish features a quick release for rapid payload changes, with multiple class leading EO/MWIR sensor options. Industry leading flight control and tracking algorithms make the Dragonfish system operable by a single operator with minimal training necessary.

Dimensions (LWH)	1290x2302x483 mm (excl.propellers) 1465x2496x483 mm (incl.propellers)
Weight(incl. batteries, propellers, excl. gimbal)	7.5 kg
Max. extra payload weight	1.5 kg
Max. takeoff weight	9 kg
Supported Payloads	DG-L20T
Operating Frequency	900M: 902 - 928MHz* 2.4G: 2.400 – 2.476GHz，2.400 – 2.4835GHz 5.2G: 5.15 – 5.25GHz* 5.8G: 5.725 - 5.829GHz，5.725 - 5.850GHz** Only applies to FCC and ISED regions * Only applies to SRRC regions * Only applies to FCC and RCM regions ** Only applies to FCC, ISED, CE and RCM regions Note: Some frequencies are only available in some regions or in door. For details, please refer to local laws and regulations.
Equivalent radiated power (EIRP)	900M: ≤30dBm (FCC/ISED) 2.4G: ≤20dBm (SRRC/CE); ≤30dBm(FCC/ISED/RCM) 5.2G: ≤30dBm(FCC); ≤24dBm(RCM) 5.8G: ≤30dBm(FCC/ISED/RCM/SRRC); ≤14dBm(CE)
Hovering Accuracy (P-mode with GPS)	Vertical: ±0.1 m(Vision System enabled) ±0.5 m(GPS enabled) ±0.1 m(RTK enabled) Horizontal: ±0.3 m(Vision System enabled) ±1.5 m(GPS enabled) ±0.1 m(RTK enabled)
RTK Positioning Accuracy	When RTK enabled and fixed： Multi-rotor： 1 cm+1 ppm（Horizontal） 1.5 cm + 1 ppm（Vertical） Fixed Wing： 3 cm+1 ppm（Horizontal） 3 cm + 1 ppm（Vertical）
Max Angular Velocity	Pitch：180°/s Yaw：60°/s
Max Pitch Angle	20°
Max Roll Angle	35°
Max Ascent Speed	Vertical Flight Mode：4 m/s Fixed Wing Mode：5 m/s
Max Descent Speed (vertical)	Vertical Flight Mode：3 m/s Fixed Wing Mode：5 m/s
Max Flight Speed	30 m/s
Flight Speed	0m/s~17m/s（Multi-rotor） 17m/s~30m/s（Fixed Wing）
Service Ceiling Above Sea Level	6000 m
Max Wind Resistance	Fixed Wing Mode：15 m/s Vertical Flight Mode：12 m/s
Max Flight Time	107 min
Supported Gimbal Configurations	Fast Disassembly
Ingress Protection Rating	IP43
GNSS	GPS/GLONASS/BDS/Galileo
Operating Temperature	-20°C ~50°C
Single Battery Energy	277.2 Wh
Single Battery Charging Time	120 min
Recommended Battery Storage Temperature	22°C ~28°C
Battery Charging Temperature	15℃ ~40℃
Battery Operating Temperature	-20℃ ~40℃
